Production capacity | ||||||
Forging | Types | Max Weight | Max Measurement | Alloy | Temper | Standard |
Open Die Forge | cube | ≤5T | Length≤7000mm; width≤2000mm; height≤500mm |
2219 2618 2B50 2A50 2A70 2A80 2D70 2A14 2014 2A11 2A12 2024 3A21 4032 5A90 5210 5A02 5A03 5083 5A05 5A06 6A02 6061 6A02 7A04 7B04 7A09 7075 7050 7A19 7A10 |
O F H112 T3 T4 T5 T6 T62 T652 T73 T7452 T852 Etc. |
GBn223 YS/T479 ASTM B247 |
disc | ≤5T | diameter≤2500mm | ||||
ring | ≤5T |
Outer diameter of quenching parts≤2500mm; outer diameter of non-quenching parts≤4000mm; height≤500mm |
||||
cylinder | ≤5T |
Out diameter 200--800mm; Length≤2000mm; outer diameter 801-2000mm; length≤1500mm |
||||
axle | ≤8T | length≤7000mm, diameter≤800mm | ||||
Closed Die Forge | PVA≤3.0(Diameter ≤1950mm) | |||||
Complicated closed die forge parts |
PVA≤1.5㎡\ (Diameter≤1400mm) |
